Fortron FSP250-60GHT |
Peripheral
> Power Supply > Fortron > FSP250-60GHT
|
|
FSP250-60GHT
|
|
|
- SFX Form Factor
- 250W
- 80 PLUSŪ Bronze certification
- Full range & Active PFC (>0.9 @ full load)
- ErP 2013 compliant (<0,5W @ standby)
- Low ripple & noise
- OVP, OCP & SCP protection
- Ball Bearing Fan
- Dimension : 175mm W x 85mm D x 70mm H
|
|
|
|
|
|
|
1 x 20/24 PIN
|
1 x 4 PIN
|
3 x Molex
|
1 x Floppy
|
2 x SATA
|
|
|
|
ENVIRONMENTAL |
|
AC Input: 115~230V, 3.0A~1.5A, 47~63Hz
PSU Load: 20%, 50%, 100%
Effizienz: 82%, 85%, 82%
|
|
|
VOLTAGE |
+5V
|
+12V1
|
+12V2
|
+3.3V
|
-12V
|
+5Vsb
|
MAX.LOAD |
16.0A
|
14.0A
|
16.0A
|
14.0A
|
0.5A
|
2.5A
|
MIN.LOAD |
0.3A
|
1.0A
|
1.0A
|
0.5A
|
0.0A
|
0.0A
|
REGULATION |
± 5%
|
± 5%
|
± 5%
|
± 5%
|
± 10%
|
± 5%
|
RIPPLE&NOISE(mV) |
70
|
140
|
140
|
70
|
140
|
70
|
Remarks:
Total continue power supply output : 250W
The combined power on +3.3V & +5V : 103W
max
The combined power on +3.3V, +5V & +12V
: 228W max
All specifications are subject to change without
prior notice.
|
|
|
|
|
|
|
